The Divider 170 TG Snow ARGB is an ATX micro tower case that comes with two preinstalled 120mm ARGB PWM fans, one tempered glass window on the left side, and can support up to a 280 mm radiator at the front
Thermaltake Divider 170 TG Snow ARGB Micro Chassis
Thermaltake designed a brand-new case series that containing stylish side panels and powerful airflow performance blending all the functionality into the Divider Series.
Modern design with Divider 170 TG Snow ARGB’s left panel gives the chassis a unique look while offering a great view of the interior. With two pre-installed ARGB PWM fans, you can enhance the cooling performance with exceptional customizable lighting. The Divider 170 TG Snow ARGB Micro Chassis is the next-gen gaming PC case for regular users, enthusiasts, and gamers, giving them unprecedented satisfaction.
All-in-One Compatibility List
| 120
mm | 240
mm | 360
mm | 140
mm | 280
mm | 420
mm |
|---|
| Front |
● |
● |
- |
● |
● |
- |
| Top |
● |
● |
- |
● |
- |
- |
| Rear |
● |
- |
- |
- |
- |
- |
Fan Support List
Fan Compatibility List
| 120mm | 140mm | 200mm |
|---|
| Front |
3 |
2 |
- |
| Top |
2 |
2 |
- |
| Rear |
1 |
- |
- |
| P/N |
CA-1S4-00S1WN-00 |
|---|
| Series |
Divider |
|---|
| Case Type |
Micro Case |
|---|
| Dimension (H x W x D) |
426 x 210 x 408.5 mm
(16.8 x 8.3 x 16.1 inch) |
|---|
| Net Weight |
5.26 kg / 11.6 lbs. |
|---|
| Side Panel |
3mm Tempered Glass x 1 |
|---|
| Color |
Black |
|---|
| Material |
SPCC |
|---|
| Cooling System |
Front(intake):
120 x 120 x 25 mm ARGB PWM fan (1500rpm, 27.2 dBA) x 2 |
|---|
| Expansion Slots |
4 |
|---|
| Motherboards |
6.7” x 6.7” (Mini ITX), 9.6” x 9.6” (Micro ATX) |
|---|
| I/O Port |
USB 3.0 x 2, USB 2.0 x 1, HD Audio x 1 |
|---|
| PSU |
Standard PS2 PSU (optional) |
|---|
| Fan Support |
Front:
3 x 120mm, 2 x 120mm, 1 x 120mm
2 x 140mm, 1 x 140mm
Top:
2 x 120mm, 1 x 120mm
2 x 140mm, 1 x 140mm
Rear:
1 x 120mm |
|---|
| Radiator Support |
Front:
1 x 240mm, 1 x 120mm
1 x 280mm, 1 x 140mm
Top:
1 x 240mm, 1 x 120mm
1 x 140mm
Rear:
1 x 120mm |
|---|
| Clearance |
CPU cooler height limitation:
160mm
VGA length limitation:
300mm(With radiator)
350mm(Without radiator)
PSU length limitation:
200mm (With HDD Cage) |
|---|
