ThermalTake 650watt Smart BX1 Bronze PSU MODEL : PS-SPD-0650NNSABA-1 psTH650_smart_bx1

tweet_button ThermalTake 650watt Smart BX1 Bronze PSU MODEL : PS-SPD-0650NNSABA-1  - GameDude Computers
ThermalTake 650watt Smart BX1 Bronze PSU MODEL : PS-SPD-0650NNSABA-1
bx1_119614332bx1abx1b
RRP: $129.00
Our price: $89.00 each

Brand: ThermalTakeThermalTake

Smart BX1 650W (230V)

Built to deliver 80 PLUS Bronze with 88% power efficiency, the Smart BX1 series is available in 450W - 750W models. Constructed with a 120mm hydraulic bearing fan, Japanese main capacitors and other premium components to help deliver a continuous and stable power output at 40℃, near silent operation and reliable performance. With an ample 5-year warranty, the Smart BX1 is able to satisfy the market, where value-oriented users are looking for a new power supply with all the latest features.

P/N PS-SPD-0650NNSABx-1
Model SPD-650AH2NKB-2
Type ATX 12V v2.3 and EPS v2.92
Max. Output Capacity 650W
Peak Output Capacity 780W
Color Black
Dimension ( W / H / D ) 150mm(W) x 86mm(H) x 140mm(D)
PFC (Power Factor Correction) Active PFC
Power Good Signal 100-500 msec
Hold Up Time > 16msec at 70% of full load
Input current 10A max.
Input Frequency Range 50Hz
Input Voltage 230V~
Operating Temperature 5°C to + 40°C
Operating Humidity 20% to 85%, non-condensing
Storage Temperature -40°C to + 55°C
Storage Humidity 10% to 95%, non-condensing
Cooling System 12cm Hydraulic bearing fan
Efficiency Meet 80 PLUS®Bronze 230V EU certified
MTBF 100,000 hrs minimum
Safety Approval CE, CB, TUV, EAC, RCM
PCI-E 6+2pin 2
