SilverStone ECS07 5-Port SATA Gen3PCIe storage expansion card sataSIecs07

tweet_button SilverStone ECS07 5-Port SATA Gen3PCIe storage expansion card - GameDude Computers
SilverStone ECS07 5-Port SATA Gen3PCIe storage expansion card
pro_20220704122459_0pro_20220704122459_2pro_20220704122459_8pro_20220704122459_4pro_20220704122459_5
$69.00 each
Brand: SilverstoneSilverstone

ECS07
5-Port SATA Gen3 6Gbps Non-RAID M.2 PCIe storage expansion card
  • Support 5 SATA Gen3 6Gbps ports
  • Aluminum alloy heatsink for great stability and heat dissipation
  • M.2 PCIe (NVMe) interface
  • Support device sleep power management
  • Plug & play with no additional driver necessary
  • Support SATA plug-in detection
  • Comply with SATA Specification Revision 3.2.
Product Specifications
Model No.
SST-ECS07
Controller-IC
JMicron JMB585
Host interface
M.2 PCIe Gen3x2
SATA Ports
5
SATA port bandwidth
6Gbps
Drive Support
SATA hard drive
PCI-E bandwidth
Up to 16GT/s
Dimension
24.8mm (W) x 10.3mm (H) x 80.5mm (D)
0.97" (W) x 0.41" (H) x 3.17" (D)
Net weight
23g



Payment Options

We accept CASH, EFTPOS, VISA or Master Card.
Credit cards incur 2% surcharge and are in store only.

We accept Direct Deposit for orders being freighted.

Important Information

Prices and specifications are subject to change.
Images are for illustration purposes and may be different to final product.

Please check the manufacturer's website for up to date specifications
