Material: ABS&metal
Color: Black & Blue
Wire length: 8CM
Product Interface: USB 3.0 19PIN
Support System: Compatible with all WINDOWS systems, LINUX MAC
Weight: about 280g (including packaging)
CHIP: GL3520
Front Panel Ports:
7 USB 3.0 Type-A Female Ports
USB 3.0 Connection Options:
USB 3.0 20-pin Header Cable
USB 3.0 Port Cable
Mounting Options: 5.25inch CD-ROM Drive Bay
Back Connectors: SATA Power Connector,USB 3.0 Type-A Female Port, SATA Power Connector
Data Transfer Rate: Up to 5Gbps
Product features: 19PIN to 7 USB3.0
Product use: With the popularity of USB3.0, more and more motherboards now have a USB3.0 19pin socket, the chassis does not have a front USB3.0 port, you can use this panel, as long as through the panel A 19PIN socket is plugged into the mainboard, which leads to seven front USB3.0 ports and is installed in an idle optical drive. USB3.0 adds SATA to enhance power and can provide enough current for 7 high-speed USB interfaces, solving the problem of insufficient power supply for the front chassis.
Hardware requirements:
With two USB3.0 20Pin interface boards or adapters, with a 5.25-inch optical drive chassis.
Note: This product can transfer 7 USB 3.0 as long as one 19PI
Package Contents:
1x drive panel
1x19PIN-AM line
5x fixing screws
1x power cord.
1.7 port usb 3.0 hub with portBackward compatible with USB 2.0/USB 1.1/USB 1.0
2.Connect up to 7 USB 3.0 devices
3.Fit any 5.25inch computer case front bay
SuperSpeed ??USB 3.0 supports up to 5 Gbps of bandwidth
4.Support variety of USB devices including scanners, printers, digital cameras, camcorders, speakers, mice, keyboards, external drives, MP3 players and more.
