SilverStone CS351 5-bay Micro ATX NAS Case Model:SST-CS351 casSIcs351*

tweet_button SilverStone CS351 5-bay Micro ATX NAS Case Model:SST-CS351 - GameDude Computers
SilverStone CS351 5-bay Micro ATX NAS Case Model:SST-CS351
pro_20220329053853_0pro_20220329053853_3pro_20220329053853_1pro_20220329053854_7pro_20220329053854_5
$279.00 each
Brand: SilverstoneSilverstone

CS351
5-bay SAS-12G / SATA-6G hot-swappable high performance NAS chassis
  • Hot-swap drive trays support up to five 3.5" or 2.5" SAS-12G / SATA-6G drives with two LED indicators for displaying drive status*
  • Drive tray features anti-theft lock design to keep confidential information secured
  • Supports 8 x 2.5" hard drive and up to 7 x 3.5" hard drives**
  • Accommodates Micro-ATX motherboard and ATX PSUs.
  • Supports up to 368mm (14.5") expansion cards**
  • Front I/O includes USB Type-C x 1, USB 3.0 x 2, combo audio x 1
  • Ample space for CPU cooling (82mm in height)
Product Specifications
Model No.
- SST-CS351
Material
- Plastic front panel, galvanized steel body
Motherboard
- Micro-ATX, Mini-DTX, Mini-ITX
Drive bay
External
  • 3.5" / 2.5" SAS / SATA hot-swap x 5
Internal
  • 3.5" x 2
    2.5” (5 ~ 9.5mm) x 1 + 2.5” (15mm) x 7**
Cooling system
Rear
  • 40mm x 3 (optional)
Top
  • 80mm x 2 (optional)
Internal
  • 80mm x 1
Limitation of CPU cooler
- 82mm
Expansion slot
- 4
Limitation of expansion card
- 368mm (14.5”) **
Power supply
- Standard PS2 (ATX) (optional)
Limitation of PSU
- 160mm ***
Front I/O port
- USB Type-C x 1
- USB 3.0 x 2
- Combo audio x 1
Dimension
- 265mm (W) x 209mm (H) x 411mm (D) , 25.1 Liters
- 10.43" (W) x 8.23" (H) x 16.18" (D) , 25.1 Liters
Net weight
- 5 kg
* With Mini-SAS HD (SFF8643) ~ SATA 7 pin cable, paired with 12 Gbit/s SAS HD card, can achieve 12 Gbit/s of high performance speed. (i.e SilverStone CPS05 & ECS05)
** The amount of 2.5” hard drives installed will affect the length of the expansion cards that can be supported. For more details, please refer to the manual.
*** The maximum depth of the PSU can reach 160mm. Due to the unique structure design of CS351, it is recommended that the depth should not exceed 150mm to avoid connector interference
