PRO AP243TP 12M
SPECIFICATIONS
CPU
Intel® Core™ i5-12400
OS Windows 11 Home
Windows 11 Pro - MSI recommends Windows 11 Pro for business
Chipset Intel® SoC
Storage 1x M.2 SSD (PCIE/SATA auto-switch)
1x 2.5” HDD / SSD
Graphics Intel® Iris® Xe Graphics (Core i5 above)
Panel
Resolution
23.8" IPS Grade Panel LED Backlight (1920*1080 FHD) with MSI Anti-
Flicker technology
Touch Panel In-cell 10-point Touch
SSD 2x DDR4 2666/3200MHz SO-DIMMs, up to 64GB
Audio
Speaker 2x 2.5W
I/O
Side:
2x USB 2.0 Type A Rear: 1x HDMI out (2.0b) 1x DP out (1.4) 1x RJ45
1x USB 3.2 Gen 2 Type C 1x USB 3.2 Gen 2 Type A 2x USB 3.2 Gen 1
Type A 1x Mic-in 1x Line-out
Audio Realtek ALC897
LAN Realtek RTL8111H
Wireless LAN 1. Intel Wi-Fi 6E AX211 2. Intel Wi-Fi 6 AX201 3. Intel Wireless AC
3168 (either one)
Bluetooth 5.2 (with Intel AX211/AX201) / 4.2 (with Intel AC 3168)
Webcam Built-in FHD Webcam which supports Windows Hello
Removable webcam cover design
Keyboard /
Mouse Optional
AC Adapter 120W
Adjustment
(Tilt) -4° ~ 20°
MANAGEMENT
UTILITY
MSI Center: Hardware Monitoring, Free Up Memory, Clean Up Disk,
LAN Manager, MSI Recovery, F3 Recovery, Devices Speed Up, Smart
Priority, Smart Image Finder, Noise Cancellation, Live Update,
Microsoft App Update, System Info, Troubleshooting, Contact Us, MSI
Forum & Channel MSI Display Kit: Split Window, Display Setting
(Orientation, resolution, refresh rate, size of text and app), Display
Color Setting (Customizable Link App: Eye Saver Mode, Personal
setting, Standard, Gaming, FPS, RTS/RPG, Cinema), Connect to
wireless display, On-screen keyboard, Mouse Sensitivity, Power
setting, Magnifier (Zoom in / Zoom out), Project way setting (internal/
Clone/ Extend/ External)
SECURITY
UTILITY &
DEVICE
MSI Center: System Diagnosis, Tile (Find My Device) Tobii Aware: -
Security and Privacy: Privacy Screen/ Auto Lock/ Peeker Detection -
Dim Screen: Energy saving - Windows Snap - TPM 2.0 Support
REGULATORY
COMPLIANCE FCC CB/CE UL & CUL VCCI RCM
Net Weight 7.42 kg / 16.36 lbs
Gross Weight 10 kg / 22.05 lbs
Certificates FCC, CB/CE, UL & CUL, VCCI, RCM
