Built-in processor: Y
Processor manufacturer: Intel
Processor family: Intel® Core™ i5
Processor generation: 11th gen Intel® Core™ i5
Processor model: i5-1135G7
Processor cores: 4
Processor threads: 8
Processor lithography: 10 nm
Processor boost frequency: 4.2 GHz
Processor cache: 8 MB
Thermal Design Power TDP: 28 W
CPU configuration max: 1
Memory slots type: SO-DIMM
Number of memory slots: 2
Number of DIMM slots: 2
Maximum internal memory: 64 GB
Supported memory clock speeds: 3200 MHz
Supported memory types: DDR4-SDRAM
Memory channels: Dual-channel
ECC: N
Supported storage drive types: SSD
Storage drive sizes supported: M.2
SSD form factor: M.2
Storage drive interface: M.2
Number of storage drives supported: 2
On-board graphics card: N
Graphics card family: Intel
On-board graphics card model: Intel Iris Xe Graphics
Number of displays supported: 4
Built-in speakers: N
Top Wi-Fi standard: Wi-Fi 6 (802.11ax)
Wi-Fi standards: Wi-Fi 6 (802.11ax)
WLAN controller model: Intel Wi-Fi 6 AX201
Ethernet LAN: Y
Wi-Fi: Y
LAN controller: Intel I225-LM
Bluetooth: Y
USB 2.0 ports quantity: 1
USB 3.2 Gen 1 3.1 Gen 1 Type-A ports quantity: 3
Internal USB 2.0 ports quantity: 2
Internal USB 3.2 Gen 1 3.1 Gen 1 ports quantity: 1
HDMI ports quantity: 2
DisplayPorts quantity: 1
Ethernet LAN RJ-45 ports: 1
Thunderbolt ports quantity: 2
Serial port via internal header: Y
M.2 card slot wireless: 2230 (E-key) (E)
USB ports quantity: 4
Thunderbolt 3 ports quantity: 1
M.2 card slot storage: 2280 NVMe (M); 2242 SATA (B)
DC-in jack: Y
PCI Express slots version: 4.0
Chassis type: UCFF
Product colour: Black
Onoff switch: Y
Product type: Mini PC barebone
Status: Launched
ARK ID: 205603
Motherboard form factor: UCFF
Windows operating systems supported: Windows 10 x64,Windows 10 IoT Enterprise
Linux operating systems supported: RedHat EL Linux,Ubuntu 20.04 LTS
Compatible operating systems: Windows 10 IoT Enterprise*|Linux*
Commodity Classification Automated Tracking System CCATS: G157815L2
Harmonized System HS code: 8471500150
Export Control Classification Number ECCN: 5A992C
Embedded options available: N
Intel AES New Instructions Intel AES-NI: Y
Intel Virtualization Technology for Directed IO VT-d: Y
Intel VT-x with Extended Page Tables EPT: Y
Idle States: Y
Intel Trusted Execution Technology: N
Intel ME Firmware Version: 15
Intel Stable Image Platform Program SIPP: N
Intel Optane Memory Ready: N
Intel Platform Trust Technology Intel PTT: Y
Intel Virtualization Technology VT-x: Y
Power supply type: External AC adapter
Power supply: 28 W
Number of power supply units: 1
AC adapter output voltage: 12 - 24 V
Width: 117 mm
Depth: 112 mm
Height: 37 mm
Launch date: Q1'21
Additional headers: Front_panel (PWR, RST, 5V, 5Vsby, 3.3Vsby); Internal 2x2 power connector
DC input voltage: 12 - 24 V
